Backups

Argos takes local tar.gz snapshots of its own DB + the Caddy state on a schedule you set. Everything lives under /data/backups/ inside the argos container, backed by the argos_data named volume.

Off-site replication is NOT argos' responsibility — mirror the /data/backups/ directory with rclone / borg / rsync as a sidecar if you need it.

What is in each archive

A tar.gz under /data/backups/argos-backup-<ts>.tar.gz containing:

  • argos.db — a VACUUM INTO snapshot of the live DB. Fully consistent, no WAL residue. Same schema as the running DB.
  • metadata.json — argos version, git commit, schema version, kind (manual / scheduled / orphan), timestamp UTC, count of caddy files actually included (see below).
  • caddy/ (optional) — copy of the Caddy data directory as seen by the argos container (read-only mount). Holds TLS certs + ACME state.

The caddy subtree is best-effort. caddy_data is mounted read-only into argos; some files under it may be owned by root (caddy container runs as root by default) and unreadable by the nobody user argos runs as. Those files are skipped silently; metadata.json records the actual count written.

If the caddy count is zero on every backup, set up the volume permissions so argos can read /caddy_data and redo the next scheduled run.

Scheduler

One cron expression owns the schedule. Settings:

  • backup.enabled — true / false. Default true.
  • backup.schedule — cron expression (minute, hour, day, month, dow). Default 0 2 * * * (02:00 UTC daily).
  • backup.retention_days — int, default 14. After each run, archives older than N days are deleted (both the tar.gz on disk and the row in backups).
  • backup.path — display-only; the actual path is /data/backups/ inside the container, baked into the image.

Change via System → Settings → Backups. The scheduler picks up the new cron on next restart; edits do NOT hot-reload today. There is no risk of a missed run because the tick only fires on wall-clock cron matches, not on a countdown.

System Settings Backup section with enabled toggle, cron expression field, and retention days

Manual backup

Backups → New backup. Adds a row with kind='manual', runs the same pipeline as the scheduled job, surfaces the tar.gz in the list. Useful before an upgrade.

Manual backups honour the SAME retention window as scheduled ones — if you take a manual backup as an anchor before a risky change, consider backup.retention_days to make sure it survives.

Verify integrity

Every row has a sha256 column. From inside the container:

docker compose exec argos sh -c '
  cd /data/backups && sha256sum -c <(sqlite3 /data/argos.db \
    "SELECT sha256 || \"  \" || filename FROM backups")
'

Mismatches indicate disk corruption on the backup volume.

Restore

Three paths, documented in Restore from backup:

  • In-place from the Backups tab (restart required).
  • CLI from the container when the panel is unreachable: argos restore --file <path> --yes.
  • HTTP upload + restore endpoint (authed) when you need to load an archive that is not in the current Backups tab.

All three write /data/.restore_pending as a restart marker and let the next boot extract.

Orphan reconcile

The backup manager also reconciles the filesystem vs the DB on boot:

  • A tar.gz present on disk but not in the backups table gets a row with kind='orphan'. You can still restore from it.
  • A row in the backups table whose file is missing is deleted from the table on the next reconcile.

This means copying a backup onto the volume from another host works: restart the container, the orphan appears in the list.

What is NOT backed up

  • CrowdSec's DB (crowdsec_data volume). Separate concern; the feed re-downloads on its own, and bouncer bans from local detection reset.
  • In-memory state: pending OIDC logins, TOTP challenges, ForwardAuth cache, notification rate-limit buckets. All intentionally ephemeral.
  • Caddy's access + error logs. These live as files that argos' log ingestor tails into log_entries; the rows up to the backup point are included, anything after is gone with the log files.

Disk sizing

A homelab panel with 10-20 hosts produces tar.gz in the ~10-50 MB range each. With retention_days=14 you expect ~200-700 MB of backups volume. Scale linearly with host count.

Gotchas

  • Clock-skew collisions: archive filenames encode the UTC timestamp to the second. If the host clock jumps backwards during a run and a same-second backup already exists, argos appends -1, -2 etc. Beyond 100 collisions it aborts — clock sync is broken.
  • Disk full: the manager does NOT pre-check free space. A run that fills the volume leaves a partial .partial file which is cleaned up on the next boot's orphan reconcile.
  • Backups do not contain .env. Secrets (session secret, master key, initial admin password) live outside the panel. Keep them in your password manager or secrets store — restoring the panel without the original ARGOS_MASTER_KEY leaves every encrypted setting (OIDC client secret, SMTP password, Telegram token, VAPID private key) unrecoverable.
